NEOSEED NR-7314 is a fluorine-free water repellent characterized by anti-wicking properties that prevent water from penetrating.
Even when the surface of the fabric is wet and sticky, it prevents water from penetrating. Processing shoes, bags, etc. improves the functionality of the product.
Even if it gets wet, it will not soak in Anti-wicking properties
The anti-wicking property of NEOSEED NR-7314 demonstrates its effectiveness when the fabric is continuously exposed to water.
This movie shows a comparison test in which polyester sneakers were treated on one side with NR-7314 and on the other with a conventional fluorine-free water repellent. It clearly highlights the excellent anti-wicking property of NR-7314.
Test result
Wick rise test
This is a wick rise test that measures the absorption of water from the cross section of the fabric. NR-7314 does not absorb water at all.
【After 2 hours】
Fabric: 100% Polyester (knit)
Recipe: Water Repellent + Crosslinking agent
Treatment: Pad → Dry 130℃ → Cure 170℃
Test method: The absorption of water from the lower part of the test fabric, measures for 2 hours.
Anti-soaking test
Drop water onto a water-repellent fabric and compare its anti-soaking properties. NR-7314 does not soak into fabric at all.
【After 2 hours】
Fabric: 100% Polyester (knit)
Recipe: Water Repellent ＋ Crosslinking agent
Treatment: Pad → Dry 130℃ → Cure 170℃
Test method: Drop 2cc of water onto the fabric and observe for 2 hours.
